18um large pixel size with super-sensitivity
Clear imaging with 800×600 resolution
55mm overlength exit pupil distance
Low latency wireless digital image
All-weather use
Interface expandable supporting customization
Outdoor night vision
Police enforcement
Urban anti-terrorism
Camping adventure
Long range observation and aiming
Image Sensor Parameter |
|
Image sensor dimension |
1 inch(18mm) |
Image resolution |
800×600 |
Pixel size |
18μm |
Minimum lllumination (no Light Compensation) |
0.0001Lx |
OLED resolution |
800×600 |
Optical Parameter |
|
Objective lens focal length |
80mm |
Relative aperture of the objective |
F1.4 |
Exit pupil distance |
55mm |
Visual magnification ratio |
3× |
FOV |
Greater than 10.3°×7.7° |
The parameters of the entire machine |
|
Boot time |
Less than 4s |
Battery |
18650 rechargeable lithium battery |
Continuous working time |
No less than six hours |
Size |
213×80×92(mm) |
Mechanical interface |
Picatinny rail |
Extensible electrical interface |
9-core aviation socket |
Degree of protection |
IP68 |
Weight (including battery) |
750g |
Environmental adaptability |
Operating Temperature:-20℃~55℃ (The minimum temperature can be extended to -40℃) |
Storage Temperature:-25℃~55℃ (The minimum temperature can be extended to -45℃) |
|
DRI for Human |
3780m(Detection)/1260m(Recognition)/629m (Identification) |
DRI for Vehicle |
5110m(Detection)/1700m(Recognition)/851m (Identification) |
