Radifeel Handheld Thermal Binoculars – HB6S
Key Features
LWIR 640×512 Detector , Ultra Clear Imaging
GPS / Beidou Positioning, Accurate Positioning Information offered
Electronic Compass，Orientation Sense in the Complex Field
IP67 Water Proof & Dust Proof ，Built for Rough Environment,Operation Temperature -40℃~+50℃
Standard Interfaces, High Compatibility for System Integration
Long Detection Range，Real-time Display and High Sensitivity
Video Recording and Picture Capture
Application Scenario
Recon
Observation
Outdoor
Security
Hunting
Monitoring
Night Vision
Law Enforcement
Specifications
|
Resolution |
640×512 |
|
Detector pitch |
17μm |
|
NETD |
≤45mK@25℃ |
|
Spectral Range |
8μm～14μm |
|
Frame Frequency |
25Hz |
|
Focal Length |
54mm |
|
Focus |
Manual |
|
Display |
0.39″OLED, 1024×768 |
|
Digital zoom |
2x |
|
Image adjustment |
Auto＆Manual shutter correction; brightness; contrast; polarity; image magnification |
|
Detection range |
Man 1.7m×0.5m：1800m |
|
Vehicle2.3m：2800m |
|
|
Identification Range |
Man 1.7m×0.5m: 600m |
|
Vehicle2.3m:930m |
|
|
Storage of image |
BMP |
|
Storage of video |
AVI |
|
Storage card |
32G TF |
|
Video out |
Q9 |
|
Digital interface |
USB |
|
Camera Control |
RS232 |
|
Tripod mounting |
Standard, UNC ¼"-20 |
|
Angle shows |
Electronic compass |
|
Positioning system |
Beidou/GPS |
|
Wireless transmission |
WiFi |
|
Battery |
Two 18650 chargeable lithium batteries |
|
Starting time |
About 10s |
|
Operating Temperature |
-40℃～+50℃ |
|
Weight |
≤1.30kg(including two 18650 lithium batteries ) |
|
Size |
200mm×160mm×81mm |
Imaging effect image
-
